Brand: COMP Cams
Product Line: COMP Cams High Energy Cam and Lifter Kits
Part Type: Camshaft and Lifter Kits
Cam Style: Hydraulic flat tappet
Basic Operating RPM Range: 1,200-5,500
Intake Duration at 050 inch Lift: 212
Exhaust Duration at 050 inch Lift: 212
Duration at 050 inch Lift: 212 int./212 exh.
Advertised Intake Duration: 260
Advertised Exhaust Duration: 260
Advertised Duration: 260 int./260 exh.
Intake Valve Lift with Factory Rocker Arm Ratio: 0.459 in.
Exhaust Valve Lift with Factory Rocker Arm Ratio: 0.459 in.
Valve Lift with Factory Rocker Arm Ratio: 0.459 int./0.459 exh. lift
Lobe Separation (degrees): 112
Intake Valve Lash: 0.000 in.
Exhaust Valve Lash: 0.000 in.
Grind Number: 260h
Computer Controlled Compatible: No
Lifters Included: Yes
Lifter Style: Hydraulic flat tappet
Valve Springs Included: Yes
Outside Diameter of Outer Spring (in): 1.230 in.
Retainers Included: No
Locks Included: No
Valve Stem Seals Included: Yes
Timing Chain and Gears Included: Yes
Timing Chain Style: Double non-roller
Assembly Lubricant Included: Yes
Pushrods Included: No
Rocker Arms Included: No
Gaskets Included: No
Quantity: Sold as a kit.
Cam/Lifters/Valvetrain, Hydraulic Flat Tappet, Advertised Duration 260/260, Lift .459/.459, GM, 3.8L, V6, Kit
COMP Cams High Energy cam and lifter kits are designed for street engines with an 8:1 to 9:1 compression ratio. They also work well with all stock components, including intakes, exhaust manifolds, and carburetors. These kits offer good increases in both gas mileage and power throughout the rpm range for most street applications.
